技術參數：
| 產品型號Model | 公稱通徑Nominal flux | 工作壓力Working pressure | 工作介質Working medium | 工作溫度Working temperature | 相對壓力0.6mpa時流量 Flux onpressure at 0.6 mpa | 排氣噪音壓力0.6mpa（距1米外） Air outlet noise pressure 0.6 mpa(outside 1 meter) |
| G1/8＂M10×1 | φ4 | 0-1.0（Mpa) | 過濾壓縮空氣Filtrated& Compressed air | -10-+70° | 0-6501/mm | 88dB(A) |
| G1/4＂M12×1.25 | φ6 | 0-14501/mm | 85dB(A) | |||
| G3/8＂M16×1.5 | φ8 | 0-206001/mm | 85dB(A) | |||
| G1/2＂M20×1.5 | φ10 | 0-39501/mm | 83dB(A) | |||
| G3/4＂M27×2 | φ15 | 0-92001/mm | 80dB(A) | |||
| G1＂M33×2 | φ20 | 0-162401/mm | 80dB |
